Reinforcing Mesh Welding Machine (12 years factory+manufacturer)

Price:	10235.65~24563.89 USD
Payment Terms:	T/T,L/C,WU
Place of Origin:	Hebei, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Means of Transport: Ocean

Packing: plastic bag

Power: Cnc

Automation: Automatic

Material / Metal Processed: Carbon Steel

Production Capacity: 400sets/year

Delivery Date: 30 days

Raw Material: Steel Bar

Certification: ISO 9001:2000

Brand Name: hengtai

Wire diamter:5-12mm
Mesh size:50X50-200X200MM
Width:max 3000mm

Function Characteristics:It adopts synchronous control skill.The welding time and separate welding are controlled by computer based on windows operation system,which makes the operation more intelligentized.The longitudinal wires are fed continually in coils,which can be straightened,cut,welded,and placed in order automatically,mesh drawing system is controlled by servo motor which improves the precision of mesh opening size,meanwhile the longitudinal and transversal spacing are adjustable.
The magor feature of this machine is that is realizes continual welding in coil wires.In addition,it simplifies the process that every tensile spring has to be changed when the welding wire diameter is different.You only need to switch the control button of are cylinder to change the pressure of welding point.
Application:Highway,railway,bridge,enclosure mesh,fencing construction and so on.

Main Parameter:

Wire Diameter	5-12mm	Rated voltage	380V
Welding Aperture	Line wire space100-300mm,weft wire space100-300mm	Rated electrical power	150KVA×6
Width of Mesh	2500mm	Welding speed	30times/minute
Number of Warp	26	Overall dimension	20x3.6x2.5M
